Frame - Spark RC Carbon HMFIntegrated Suspension TechnologyFlex Pivot / Adjustable head angleSyncros Cable Integration SystemBB92 / UDH Interface / 12x148mm with 55mm Chainline
Fork - FOX 32 Float Rhythm Grip3-Modes / Kabolt 15x110mm axle / 44mm offset / tapered steererReb. Adj. / Lockout / 120mm travel
Rear Shock - FOX Float Custom EVOL Performace Trunnion3 modes / Lockout-Trail-DescendDPS / Reb. Adj.Travel 120mm / T165X45mm
Remote System - SCOTT TwinLoc 2 Technology3 Suspension modes
Rear Derailleur - SRAM NX Eagle 12 Speed
Shifters - SRAM NX Eagle Trigger
Crankset - SRAM NX Eagle DUB55mm CL / 32T
BB-Set - SRAM DUB PF 92 MTB Wide / shell 41x92mm
Chain - SRAM CN NX Eagle
Cassette - SRAM SX-PG1210 / 11-50 T
Brakes - Shimano Deore M6100 Disc
Rotor - Shimano SM-RT64 CL / 180/F and 160/R
Handlebar - Syncros Fraser 2.0 XC Alloy 6061 D.B.Flat Bar / 8° / 740mmSyncros Performance XC lock-on grips
H'stem - Syncros XC 2.0Syncros Cable Integration System-12° rise / 6061 Alloy / 31.8mm / 1 1/8"
Seatpost - Syncros Duncan 2.0 / 10mm offset31.6x400mm
Seat - Syncros Belcarra Regular 2.0CRMO rails
Headset - Syncros - Acros Angle adjust & Cable Routing HS System+-0.6° head angle adjustmentZS56/28.6 – ZS56/40 MTB
Hub (Front) - Formula CL-811 / 15x110mm
Hub (Rear) - Formula CL-148S / 12x148mmSyncros Axle w/Removable Leverwith 6mm Allen, T30 and T25 Tools
Spokes - Stainless Black 15G / 1.8mm
Rims - Syncros X-30SE / 32H / 30mmTubeless ready
Front Tire - Maxxis Rekon Race / 29x2.4" / 60TPI Foldable BeadTubeless Ready / EXO
Rear Tire - Maxxis Rekon Race / 29x2.4" / 60TPI Foldable BeadTubeless Ready / EXO
Accessories - Transport Axle
Approx weight in KG - 12.5 (Tubeless setup)
Approx weight in LBS - 27.56 (Tubeless setup)
Max. System Weight - 128kgThe overall weight includes the bike, the rider, the equipment, and possible additional luggage.
